Blum 70T6650 UNSPRUNG 170° Half Overlay Wide Angle Hinge

Description

Blum 70T6650 UNSPRUNG 170 Degree Half Overlay Wide Angle Hinge
An unsprung hinge is required for push to open/handleless doors, and is used in conjunction with a Tip-On device.
CLIP top Wide angle hinge 70T6650.TL
Opening angle: 170 degree
Cranking: Half/Dual Overlay
Boss assembly: Screw-on
Material: Steel
Finish: Nickel plated
Closing mechanism: UNSPRUNG
3-dimensional front adjustment
Side adjustment: +/- 2 mm
Depth adjustment: + 3/- 2 mm, convenient with spiral screw
